Name: Fully Advanced Promotion Twin Shaft Compulsory Fly Ash Mixer JS Serie
Availability: InStock

Fully Advanced Promotion Twin Shaft Compulsory Fly Ash Mixer JS Serie

Reference video of Fully Advanced Promotion Twin Shaft Compulsory Fly Ash Mixer JS Serie:

The JS Serie is a fully advanced, twin-shaft compulsory fly ash mixer designed for high-efficiency mixing of fly ash, cement, and aggregates. Featuring a robust twin-shaft design with forced mixing action, it ensures uniform material distribution, consistent batch quality, and excellent homogeneity for concrete block production. The energy-efficient motor reduces power consumption while wear-resistant mixing arms and linings extend service life. A reference video is available to demonstrate the complete mixing cycle, from material feeding to discharge. Ideal for block plants seeking advanced technology, promotional pricing, and reliable fly ash mixing performance.

Tech Data

Type	JS350	JS500	JS750	JS1000
Charging Volume（L）	560	800	1200	1500
Discharging Volume（L）	350	500	750	1000
Speed of Mixing Blade（r/min）	35	35	32.6	32.6
Mixing Blade（PCS）	3	14	14	16

Product Details

The JS Serie is powered by a high-efficiency electric motor designed for reliable, energy-saving operation. This advanced motor delivers consistent torque output to drive the twin-shaft mixing action, ensuring uniform material dispersion and optimal batch quality. The energy-efficient design reduces power consumption by up to 15–20% compared to conventional motors, lowering operational costs. Overload protection and thermal safety features prevent damage during heavy mixing loads.
The JS Serie twin-shaft compulsory fly ash mixer features advanced technology for high-efficiency mixing. Key details include: heavy-duty twin mixing shafts with multiple spiral blades, wear-resistant chromium alloy linings, and a large discharge gate for rapid material evacuation. The energy-efficient motor reduces power consumption while maintaining consistent torque. A sealed bearing design prevents material ingress, extending service life. The user-friendly control panel allows adjustable mixing cycles and speed settings
The JS Serie is a fully advanced, promotion-priced twin shaft compulsory mixer engineered for fly ash and concrete batching. Its dual-shaft design with overlapping mixing tools ensures thorough material circulation, eliminating dead zones and delivering consistent homogeneity. Wear-resistant blades and linings extend service life under continuous operation. The large discharge outlet allows fast, clean evacuation, reducing cycle times. An energy-saving motor lowers electricity costs while maintaining high torque.

Block Display

The JS Serie mixer can be integrated with a block display system for quality inspection of mixed concrete and sample blocks. This feature allows operators to easily examine material consistency, color uniformity, and workability before block forming. Equipped with adjustable LED lighting and a smooth sampling table, it enables thorough visual checks of cement paste distribution and aggregate dispersion. The user-friendly layout supports quick sampling, quality control documentation, and customer viewing. Ideal for fully advanced promotion applications, this block display system enhances quality assurance, ensures consistent mix quality, and builds customer confidence in fly ash concrete block production.

Block Type

The JS Serie twin shaft compulsory mixer is designed to prepare homogeneous concrete mixtures for a wide range of block types. These include solid blocks, hollow blocks, porous blocks, interlocking pavers, curbstones, grass pavers, colored blocks, and fly ash bricks. The mixer ensures uniform cement dispersion and consistent material distribution, which is critical for producing high-strength, durable blocks with excellent surface finish. Its forced mixing action handles zero-slump concrete, lightweight aggregates, and colored additives with ease. Ideal for fully advanced promotion applications, the JS Serie delivers reliable batch quality for diverse block production needs in construction and landscaping projects.

FAQ

1.What is the production capacity of the JS Serie mixer?

The JS Serie offers various models with different batch capacities. Typical output ranges from 500 to 2,000 liters per batch, depending on the specific model (e.g., JS500, JS750, JS1000, JS1500, JS2000). Production capacity per hour ranges from 10 to 50 cubic meters of mixed concrete, depending on cycle time and material composition.

2.How many days to change vibration box oil ,what kind of oil can be used inside?

The hydraulic oil 68 degree can be used, the amount is from bottom 3cm. Strongly suggest 1 month change one time oil.

3.What is the lead time?

Standard models are typically delivered within 7–15 working days after order confirmation. Customized orders may require 20–30 working days, depending on the complexity and quantity.

4. What materials can the JS Serie mixer process?

The JS Serie is specifically designed for fly ash mixtures but can also process cement, sand, gravel, crushed stone, lightweight aggregates, colored pigments, and various additives. It handles zero-slump concrete, dry-cast mixtures, and wet concrete with equal efficiency, making it ideal for block production.

5.Is the JS Serie energy efficient?

Yes, the JS Serie is designed with energy efficiency in mind. The advanced motor and optimized gearbox reduce power consumption by 15–20% compared to conventional mixers. The efficient mixing action also reduces mixing cycle times, further lowering energy costs per batch.
