Name: High Standrad Solid Block Making Machine QT18-15
Availability: InStock

High Standrad Solid Block Making Machine QT18-15

The QT18-15 solid block making machine is a high-output, reliable system for producing dense, high-strength concrete blocks. It features a robust hydraulic vibration system for rapid mould filling and compaction. The machine supports various mould sizes and operates with a user-friendly PLC control panel. Ideal for large-scale production, it ensures consistent block quality, low maintenance, and high energy efficiency.

แบบอย่าง :
Yixin Machinery QT18-15
ขนาดเครื่องจักร :
12500*2714*3100
ขนาดพาเลท :
1350*1350mm
เวลาวงจร :
15-25（S）
แรงสั่นสะเทือน :
105(KN)
ความดันเวเต็ด :
21（mpa）
พลัง :
81.38(KW)

สอบถามตอนนี้

High Standrad Solid Block Making Machine QT18-15

Reference video of QT18-15 solid block making machine

The suspended material cart on the QT18-15 is engineered for faster and more durable operation. Its robust design reduces cycle time by enabling rapid material transfer without jamming. Built with high-wear steel, the cart withstands heavy use and abrasive materials, extending service life. This improves overall productivity while lowering maintenance needs. Ideal for high-standard block production, it ensures consistent feeding, less downtime, and reliable performance under continuous, demanding work conditions.

Production Data

Block Type	Specification（mm）	Qty/Palllet	Qty/Hour	Qty/Hours
Hollow Block	400200200	18	2592	20736
Solid Block	24011553	100	25000	200000
Holland Block	20010060	66	10625	85000
Zigzag Block	225112.560	50	9000	72000

Product Detail

The block conveyor of the QT18-15 automatically transports finished blocks from the machine to the curing area. It operates seamlessly after each production cycle, reducing manual handling and improving efficiency. The robust belt and frame ensure stable transfer without damaging fresh blocks. Speed and direction are adjustable to fit different block sizes and layering needs. This conveyor helps maintain continuous output and lowers labor costs.
The pallet feeder of the QT18-15 solid block making machine automatically delivers pallets beneath the mold area, ensuring precise positioning for each production cycle. It operates with a hydraulic or pneumatic system, providing smooth and reliable pallet feeding without manual intervention. The feeder is designed to handle heavy-duty pallets, reducing labor costs and improving overall efficiency. Its adjustable speed and timing features allow seamless integration with the block making process.
The guiding system of the QT18-15 ensures precise alignment and stable movement of the mold and press head during block production. It uses heavy-duty guide posts and bushes, minimizing vibration and wear for extended machine life. This system maintains consistent compaction pressure, leading to high-density blocks with accurate dimensions. Low maintenance is required due to its sealed structure against dust.

Block Type

The double couplet pump on the QT18-15 solid block making machine integrates two hydraulic pumps in one unit for efficient power distribution. One pump supplies high pressure for mould clamping and core pulling, while the second ensures rapid material feeding and vibration. This design reduces cycle time and energy loss. It allows independent control of critical movements for smooth, synchronized operation.

Professional Shipping

The QT10-15 can be equipped with an optional secondary materials device, enabling the production of all types of colorful paving blocks. This flexibility allows you to create multi-layer blocks with premium surface color and lower-cost base materials, significantly reducing production costs. The device ensures uniform color distribution and high surface finish, expanding your product range for landscaping, walkways, and urban decoration projects.

FAQ

1.How long does the product production cycle typically take?

High Standrad Solid Block Making Machine QT18-15 can produce a variety of products including external wall blocks, internal wall blocks, PC stone permeable bricks, flower wall blocks, floor blocks, dike blocks, chain blocks, curbs, and other types of blocks.The production time for brick making machines is generally 25-30 working days, depending on the customer's production line requirements.

2. How many days to change vibration box oil ,what kind of oil can be used inside?

The hydraulic oil 68 degree can be used, the amount is from bottom 3cm. Strongly suggest 1 month change one time oil.

3.What are the raw materials used in the production process of Yixin Machinery High Standrad Solid Block Making Machine QT18-15?

The raw materials utilized in the production process of High Standrad Solid Block Making Machine QT18-15 primarily include sand, gravel, and cement. Additionally, this machine has the capability to incorporate a significant amount of industrial waste materials such as slag, coal gangue, clay, ceramisite, perlite, and others.

4.What is the estimated date of shipment for the High Standrad Solid Block Making Machine QT18-15 after mold confirmation?

The estimated date of shipment for the High Standrad Solid Block Making Machine QT18-15 is 25-30 working days following the confirmation of the mold. This timeframe allows for the necessary preparations, assembly, and quality checks to ensure that the machine is ready for dispatch and meets the customer's specifications.

5. Can the High Standrad Solid Block Making Machine QT18-15 be equipped with an additional device to produce various types of colored paving blocks?

Yes, the High Standrad Solid Block Making Machine QT18-15 can indeed be upgraded or equipped with a secondary materials device that allows for the production of a wide range of colored paving blocks.
